ECU5000

Features:

Industrial-grade design to meet the needs of industrial and power users
Utilizes industrial-grade chip design and a deeply customized Linux OS for stable and reliable system operation
Fanless design for durabilityEmbedded hardware and software watchdog technology for self-recovery from faults, ensuring stable equipment operation
Supports multiple industrial interfaces: 4G/ETH/RS485/CAN/DI/DO/USB
Millisecond response mechanism for second-level acquisition of large variables

Add To Cart Inquiry

Product Details

ECU 5000 This is a highly integrated energy storage EMS communication management unit designed specifically for the energy storage industry. It features a high-performance, low-power main control chip and rich functional interfaces for the power industry, widely meeting the needs of power sources. Applications such as cloud-edge-device energy management in integrated grid-load-storage microgrid energy storage systems .

ECU5000 product is equipped with a quad-core Cortex-A55 2.0GHz processor. It supports 8 xRS485 , 2 xRS232 , 18 x DL , 8 x DO , 3 x CAN , 4 x Eth, 4G , WIFI , SSD , and HDMI. High-performance, feature-rich interface, and more. The ECU5000 series supports Linux and Ubuntu 20.04. The operating system has secondary development support and can be customized according to the user's own business needs. It is designed to provide value to customers and can meet the needs of power storage and industrial applications.

Specifications

ECU5000 Configuration Table
Major Categories	type Details		parameter
Product Solution	Software and hardware platform	Main control chip parameters	ECU5000
		Main control chip parameters	4 CoreTX -A55 chipsets, maximum clock speed 2 GHz
		Memory size type	DDR: 4GB
		Flash memory size type	EMMC: 32GB
		operating system	Ubuntu 20.4
	network	net mouth	4-way 4*10/100/1000M adaptive, (independent IP , different network segments)
		4G	CAT 4/ CAT 1 compatible
		WIFI	2.4G (Reserved)
	DIO	DI	18-channel dry node input
	DIO	DO	8-channel relay output 5A 30Vdc
	CAN	CAN	3-channel CAN 2.0 1500V electrical isolation
	RS485	RS485	8-channel 1500V electrical isolation, default baud rate 9600
	RS232	RS232	2-channel 1500V electrical isolation, default baud rate 115200
	RTC	RTC	Built-in real-time clock
	USB	USB	2 USB 2.0-HOST
	TF	TF	1-channel 512GB MAX
	M.2 ADC	SSD	1-way mSATA /M.2 compatible with 1TB Max
	M.2 ADC	ADC	4-channel 0-10V/ 4-20mA (optional)
	show	HDMI	HD 1920*1080
	Hard drive interface	M.2	Supports SSD expansion up to 1TB
	Power failure protection	Supercapacitor	5 seconds
	Watchdog	Watchdog	support
	power supply	DC	24V input power supply, operating range 12V~30V/1A
other	Power consumption		≤15W
	Operating temperature	scope	-25℃ to 75℃
	Storage temperature	scope	-40℃ to 80℃
	Operating humidity		5%~95%
